| Engine Size |
12 Volt up to 14.8L
24 Volt up to 16.0L |
| System Voltage |
12 or 24 Volts |
| Rotation |
Clockwise
Counterclockwise |
| Mounting |
SAE #1, SAE #3 |
| Pinion |
11 Tooth, 6-8 Pitch
12 Tooth, 8-10 Pitch
13 Tooth, 8-10 Pitch
11 Tooth, MOD 3 (Metric)
12 Tooth, MOD 3 (Metric) |
| Peak Output |
12 Volt 7.3 kW
24 Volt 8.0 kW |
| Battery Internal Resistance |
12 Volt 2 mOhm
24 Volt 8 mOhm |
| Weight |
58.0 lbs / 26.3 kg |
| Frame Diameter |
5.12 in / 130 mm |
| Overall Length |
19.53 in / 496.0 mm |
| Motor Type |
Wound Field
Straight Drive |
| Pinion Support |
Nose |
| Drive Design |
Two-piece rotatable drive housing
(12 or 24 positions)
Positive Engagement
Rubber Shock Absorber |
| Optional Features |
Jumpstart Protection
(meets SAE J1493)
Over-Crank Protection |
Warranty
*(US/Canada Only) |
1 year / unlimited miles
18 month / unlimited miles - Reman |
